49-EN
Set the rating level of PARENTAL
4 Touch [ ] of Parental to turn on.
5 Touch [ ] or [ ] of Parental Level to select the rating
level (1 to 8).
Select “OFF” to cancel the parental lock or if you do not
want to set a rating level. The smaller the number, the
higher the rating level.
6 Touch [ ] to return to the previous screen.
Changing the password
4 Touch [Input] of Password Change.
The numeric keypad screen is displayed.
5 Touch the input screen to enter a new 4-digit password.
• Keep a note of the number somewhere safe in case you should
forget it.
6 Touch [Enter] to memorize the number.
7 Touch [ ] to return to the previous screen.
This function applies to Dolby Digital, DTS stream sound.
Setting item: Downmix Mode
Setting contents: Surround / Stereo
Use the procedure described below to modify the output screen
according to the type of TV monitor (rear monitor) being used.
This setting can also be applied for the INA-W900.
If the rear monitor is not connected, the screen setting is 16:9.
Setting item: TV Screen
Setting contents: 4:3 LB / 4:3 PS / 16:9
• For some discs, the picture may not be set to the selected screen size.
(For details, refer to the explanation on the disc’s jacket.)
4:3 LETTER BOX:
Select this when connected to a conventional 4:3 size (normal
TV aspect ratio) monitor. There may be black stripes visible at
the top and bottom of the screen (when playing a 16:9 size
movie). The width of these stripes will depend upon the original
aspect ratio of the theatrical release of the movie.
4:3 PAN-SCAN:
Select this when connected to a conventional 4:3 size monitor.
The picture will fill the entire TV screen. However, due to the
mismatch in aspect ratio, parts of the movie at the extreme left
and right sides will not be visible (when playing a 16:9 size
movie).
16:9 WIDE:
Select this when connected to a wide screen TV. This is the
factory setting.
When using discs containing both audio data and MP3/WMA/AAC
data.
Setting item: File Play Mode
Setting contents: CD / CMPM
• Insert the disc when playback is stopped and remove the disc from
the unit before setting.
• When an MP3-compatible CD changer is used, this setting cannot be
applied.
Changing the rating level temporarily
Some discs may request that you change the rating level set in
the default settings during playback. In this case, the message
appears on the monitor screen “Parental Level Change OK?
[YES] [NO].”
If this screen appears, change the level as follows:
• To change parental level and play, touch [YES].
When [YES] is touched, the numeric keypad input screen is
displayed. Input the 4-digit password in “Setting the Rating Level
(Parental Lock)” you set, then touch [ENT].
• To play without changing the parental level, touch [NO].
(When [NO] is touched, playback will be at the parental level set
in “Setting the Rating Level (Parental Lock).”)
Setting the Downmix Mode
Surround: Surround compatible Downmix
Stereo: Stereo Downmix
Setting the TV Screen Mode
Playing MP3/WMA/AAC Data (File Play
Mode)
CD: Plays only the audio data on discs containing both
audio data and MP3/WMA/AAC data.
CMPM: Plays only the MP3/WMA/AAC files on discs containing
both audio data and MP3/WMA/AAC data.
