Terminated cable assemblies
VGA male-to-male cables Part Number
VGA M-M MD, 3' to 100' (0.9 m to 30.4 m) (molded) 26-238-nn
VGA M-M BK, 3' to 100' (0.9 m to 30.4 m) (backshell) 26-238-nn
VGAP M-M MD, 3' to 25' (0.9 m to 7.6 m) (molded) 26-439-nn
VGAP M-M BK, 35' to 100' (10.6 m to 30.4 m) (backshell) 26-439-nn
VGA male-to-male with audio cables Part Number
VGA-A M-M MD, 3' to 50' (0.9 m to 15.2 m) (molded) 26-490-nn
VGA-A M-M BK, 3' to 50' (0.9 m to 15.2 m) (backshell) 26-490-nn
VGA-A 90º M-M BK/6, 6' (1.8 m) (molded) 26-510-02
VGA-A 90º Up M-M BK/3, 3' (0.9 m) (molded) 26-510-21
VGA-A 90º Up M-M BK/6, 6' (1.8 m) (molded) 26-510-22
VGA male-to-female cables Part Number
VGA M-F MD, 3' to 100' (0.9 m to 30.4 m) (molded) 26-112-nn
VGA M-F BK, 3' to 100' (0.9 m to 30.4 m) (backshell) 26-112-nn
VGAP M-F MD, plenum 3' to 25' (0.9 m to 7.6 m) (molded) 26-438-nn
VGAP M-F BK, plenum 35' to 100' (10.6 m to 30.4 m) (backshell) 26-438 -nn
VGA male-to-female with audio cables Part Number
VGA-A M-F MD, 3' to 50' (0.9 m to 15.2 m) (molded) 26-491-nn
VGA-A M-F BK, 3' to 50' (0.9 m to 15.2 m) (backshell) 26-491-nn
VGA-A 90º F-M BK/3, 3’ (0.9 m) (backshell) 26-509-01
VGA-A 90º Up F-M MD, 3' to 6' (0.9 m to 1.8 m) (molded) 26-509-nn
S-video cables Part Number
MHR-2 SVM-M, 6' to 100' (1.8 m to 30.4 m) 26-316-nn
MHR-2P SVM-M, Plenum, 6' to 100' (0.9 m to 30.4 m) 26-522-nn
S-video/BNC adapters Part Number
SVHSF-BNCM, S-video female to BNC male,
1' to 6' (30 cm to 1.8 m)
26-541-nn
SVHSF-BNCF, S-video female to BNC female, 8" (20 cm) 26-541-01
SVHSM-BNCM, S-video male to BNC male, 1' to 6'
(30 cm to 1.8 m)
26-353-nn
SVHSM-BNCF, S-video male to BNC female,
8" (20 cm)
26-353-01
Composite video male-to-male cable Part Number
RG6 BNC, 3' to 100' (0.9 m to 30.4 m) 26-383-nn
