DHCP radio buttons
The DHCP On radio button directs the switcher to ignore any entered IP addresses and
to obtain its IP address from a Dynamic Host Conguration Protocol (DHCP) server (if the
network is DHCP capable). The DHCP Off radio button turns DHCP off. Contact the local
system administrator to determine if DHCP is appropriate.
NOTE: When you change DHCP from on to off, the IP address of the switcher resets to
its default value, 192.168.254.254.
IP Address field
The IP Address field contains the IP address of the connected switcher. This value is
encoded in the ash memory of the switcher.
Standard IP protocol consists of addresses comprised of four 1-, 2-, or 3-digit numeric
subelds, properly called octets, separated by dots (periods). Each eld can be numbered
from 000 through 255. Leading zeroes, up to three digits total per eld, are optional. Values
of 256 and above are invalid.
The factory-installed default address is 192.168.254.254, but if this conicts with other
equipment at your installation, you can change the IP address to any valid value.
NOTE: IP address changes can cause conicts with other equipment. Only local system
administrators should change IP addresses.
Gateway IP Address field
The Gateway IP Address field identifies the address of the gateway to the mail server to
be used if the switcher and the mail server are not on the same subnet. Standard IP protocol
rules apply to the Gateway IP address.
Subnet Mask field
The Subnet Mask field is used to determine whether the switcher is on the same subnet as
the mail server when you are subnetting. Standard IP protocol rules apply to the Gateway IP
address. For more information, see “Subnetting — A Primer”.
MAC Address
The Media Access Control (MAC) Address is hardcoded in the switcher and cannot be
changed.
Firmware field
The Firmware field identifies the installed firmware version. This field is hardcoded in the
switcher and cannot be changed.
