PERIODIC MAINTENANCE AND MINOR REPAIR
6-27
6
2. Check each brake pad for damage
and measure the lining thickness.
If a brake pad is damaged or if the
lining thickness is less than 0.03 in
(0.8 mm), have a Yamaha dealer
replace the brake pads as a set.
3. Install brake caliper bolt A, then
tighten both caliper bolts to the
specified torque.
EAU04856
Checking the brake fluid level
Insufficient brake fluid may allow air to
enter the brake system, possibly caus-
ing it to become ineffective.
Before riding, check that the brake fluid
is above the minimum level mark and
replenish if necessary. A low brake flu-
id level may indicate worn brake pads
and/or brake system leakage. If the
brake fluid level is low, be sure to check
the brake pads for wear and the brake
system for leakage.
Observe these precautions:
●
When checking the fluid level,
make sure that the top of the brake
fluid reservoir is level.
●
Use only the recommended quali-
ty brake fluid, otherwise the rubber
seals may deteriorate, causing
leakage and poor braking perfor-
mance.
●
Refill with the same type of brake
fluid. Mixing fluids may result in a
harmful chemical reaction and
lead to poor braking performance.
a. Lining thickness
Tightening torque:
Brake caliper bolt:
19.5 ft·lbf (2.7 m·kgf, 27 Nm)
1. Minimum level mark
Front
1. Minimum level mark
Recommended brake fluid: DOT 4
Rear
