1993 Volvo 940
18 High beam (right) 15
19 Low beam (left), relay - fog light(s) 15
20 Low beam (right) 15
21 LH parking lights (front and rear), license plate light, light for: ash tray, heater, control panel, switch
for heated rear window 15
22 RH parking lights (front and rear), center console compartment, lighting for: heated seat switch, gear
selector panel, rear ash tray 15
23 Heated front seats 25
24 Spare
25 Rear fog light 25
26 Audio system 15
for more detailed information concerning function and location of relays, fuses, etc., refer to the Volvo
Service Manuals. These can be purchased directly using the Service Literature Brochure/Order form or
through your Volvo dealer.
* Some of the equipment/systems listed may be available on certain models only.
NOTE: On cars equipped with ABS, the system is protected by an additional 10A fuse located under
the instrument panel to the left of the steering wheel.
pg. 6:15 Replacing wiper blades, Adjusting washer nozzles
Replacing wiper blades
Lift the wiper arm off the windshield and hold blade at right
angles to arm. Pinch the end of the plastic clip located at the
back of the arm.
Slide the wiper blade along the arm to release it from the
hook.
Install new blade (installation is the reverse of removal) and
make sure that it is properly attached to the wiper arm.
for reasons of safety, you should change the windshield
wiper blades as soon as they start to leave marks on the
windshield or fail to wipe efficiently and cleanly.
