204
Controls in detail
4-zone automatic climate control
Adjusting air distribution
Use the air distribution controls 1 and 7
(
୴ page 198) or (୴ page 199) to separate-
ly adjust the air distribution on each side of
the passenger compartment.
The following symbols are located on the
controls:
̈ Turn air distribution controls 1
and 7 (
୴ page 198) or (୴ page 199)
on each side of the passenger compart-
ment to the desired symbol.
The indicator lamps on the
buttons U go out. The automatic air
distribution is switched off. The air dis-
tribution is controlled according to the
selected control setting.
Opening the center air vents
̈ Turn thumbwheels 3 and 4
(
୴ page 196) upward.
The side air vents 2 and 5 are open.
Closing the center air vents
̈ Turn thumbwheels 3 and 4
(
୴ page 196) downward.
The side air vents 2 and 5 are
closed.
Opening the side air vents
̈ Turn thumbwheels 8 and a
(
୴ page 196) upward.
The side air vents 7 and b are open.
Closing the side air vents
̈ Turn thumbwheels 8 and a
(
୴ page 196) downward.
The side air vents 7 and b are
closed.
Symbol Function
a Directs air through the cock-
pit, center, side and rear pas-
senger compartment air vents
Z Directs air to the windshield
and through the side air vents
X Directs air into the entire vehi-
cle interior
Y Directs air to the footwells
i
You can also turn the air distribution
control to a position between two sym-
bols.
