Black plate (19,1)
Change the seatback angle by pressing the
front or rear side of the reclining switch.
Release the switch at the desired position.
qHeight Adjustment
Front of seat bottom
To adjust the front height of the seat
bottom, raise or lower the front of the
slide lifter switch on the left side of the
seat.
Rear of seat bottom
Raise or lower the back of the switch to
adjust the rear height of the seat bottom.
Whole seat
Raise the seat by pulling up on the center
of the switch. Release the switch at the
desired position.
Lower the seat by pressing down on the
center of the switch. Release the switch at
the desired position.
Essential SafetyEquipment
Seats
2-7
CX-7_8V28-EA-06B_Edition2 Page19
Monday, March 13 2006 5:5 PM
Form No.8V28-EA-06B
