12 volt
battery
Switchbox
RIM 200
module
COM Port 2 (RS-
232): blue (TX) &
green (RX)
Fuse box
NMEA 2000
power cable
Display unit power cable
RIM 200 power
cable
RIM 200 data cable
(RS-422); connects to
r
adar unit
Detail Drawing C:
Four-branch Installation
*
*
*
*
*
*
* A power switch will only be
connected to the red (+)
wire. The black wire (–) will
not be connected to the
power switch.
Cable Plug
