Crimestopper Security Products EZ-45DP/55DP Remote Starter User Manual



19
DIESEL GLOW PLUG DELAY
This feature provides a solution for diesel vehicles without having to connect to the Glow Plug-“Wait to Start Circuit”. This
may be needed for various reasons. If your vehicle does not have a viable “Wait to Start Circuit”, or you cannot locate and
identify the circuit, then change your system to “Diesel Glow Plug Delay” mode. You can choose from a selection of “pre-
cranking” delay times. Once this mode is activated, the system will NO LONGER monitor the PINK glow plug input wire
and will use a delay setting chosen by the installer in the option chart.
NOTES: This feature is OFF by default and must be programmed before use. Once this feature is turned ON, the Pink
Glow plug input wire is not used. The Remote start unit will always wait the programmed time before cranking EVEN IF
the glow plug warms up first. There are 3 different Delay times available for use: 10, 20, or 30 seconds. SEE OPTION
PROGRAMMING CHART on Pages 20-21.
HOW TO USE THIS FEATURE:
1. See the “Option Programming” section on Pages 20-21 and change Option #19 from "Monitor Glow Plug Light" to
one of the delayed time values. (Default setting is to always monitor the PINK Glow Plug input wire.)
2. Once this option has changed, the system will wait for the selected time before cranking.
OPTIONS PROGRAMMING
This EZEESTART unit has 24 or 28 programmable control options depending on model to customize the system for
various operating features and installer preferences. Examine the chart on the pages 20-22 along with reading the
descriptions that follow on pages 20-25. You may change one option at a time, or program multiple options in one
session. If you start with the lowest option and continue on to higher options, you do not need to repeat steps #1-3 each
time. For example, you can change Option #2 to “ON”, then you can continue pressing the program button to get to a
higher number option and change it as well. You can only go from low to higher options numbers in one session.
OPTION PROGRAMMING CHART BEGINS ON NEXT PAGE
