Black plate (96,1)
Model "Z51-D" EDITED: 2010/ 9/ 28
SIC4703
Outside air temperature (ICY — 8For8C)
The outside air temperature is displayed in 8For
8C in the range of −22 to 1408F(−30 to 608C).
The outside air temperature mode includes a low
temperature warning feature. If the outside air
temperature is below 378F(38C), the warning is
displayed on the screen.
The outside temperature sensor is located in
front of the radiator. The sensor may be affected
by road or engine heat, wind directions and
other driving conditions. The display may differ
from the actual outside temperatur e or the
temperature displayed on various signs or bill-
boards.
SIC3678
Setting
Setting cannot be made while driving. A
message “Setting can only be operated
when stopped” is also displayed onthe dot
matrix crystal display.
The
switch
*
A
and switch
*
B
are
used in the setting mode to select and decide a
menu.
SKIP:
Push the
switch
*
A
to move to the
warning check mode.
Push the
switch
*
B
to select other menus.
ALERT:
Alert menu can be set to notify the following
items.
. TIMER
Select this submenu to specify when the
“TIMER” indicator activates.
. ICY
Select this submenu to display the low
outside temperature warning.
To return to the top page of the setting mode,
select “BACK”.
MAINTENANCE:
The maintenance intervals of the following items
can be set or reset for the reminders.
. OIL
Select this submenu to set or reset the
distance for changing the engine oil.
. FILTER
Select this submenu to set or reset the
distance for replacing the oil filter.
. TIRE
Select this submenu to set or reset the
distance for replacing tires.
2-24 Instruments and controls
