Black plate (233,1)
Model "Z51-D" EDITED: 2010/ 7/ 23
SAA3006
5. The standby message screen will appear.
Operate the compatible Bluetooth
®
audio
device. For the connecting procedure of the
audio device, see the Bluetooth
®
audio
instructions.
When the connecting is completed, the
screen will return to the Bluetooth
®
setup
display.
SAA2510
Audio main operation
Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX button
repeatedly to switch to the Bluetooth
®
audio
mode. If the system has been turned off while
the Bluetooth
®
audio device was playing, push-
ing the ON·OFF/VOL control knob will start the
Bluetooth
®
audio device.
The ability to pause, change tracks, fast forward,
rewind, randomize and repeat music may be
different between devices. Some or all of these
functions may not be supported on each device.
DISC·AUX button:
When the DISC·AUX button is pushed with the
system off and the Bluetooth
®
audio device
connected, the system will turn on. If another
audio source is playing andthe Bluetooth
®
audio
device is connected, push the DISC·AUX button
repeatedly until the display changes to the
Bluetooth
®
audio mode.
Next/Previous Track and Fast
Forward/Rewind:
When the
or button is pushed for
more than 1.5 seconds while a Bluetooth
®
audio
file is being played, the Bluetooth
®
audio device
will play while forwarding or rewinding. When
the button is released, the Bluetooth
®
audio
device will return to normal play speed.
When the
or button is pushed for less
than 1.5 seconds while a Bluetooth
®
audio file is
being played, the next track or the beginning of
the current track on the Bluetooth
®
audio device
will be played. The multi-function controller can
also be used to select tracks when the Blue-
tooth
®
audio play mode screen is shown on the
display. (“Bluetooth audio” will be indicated on
the header of the screen.)
Center display, heater, air conditioner, audio, phone and voice recognition systems 4-65
