Black plate (369,1)
Model "Z51-D" EDITED: 2010/ 7/ 23
CAUTION
. Use only Genuine NISSAN CVTFluid
NS-2. Do not mix with other fluids.
. Using transmission fluid other than
Genuine NISSAN CVT Fluid NS-2
will damage the CVT, which is not
covered by the NISSAN new vehicle
limited warranty.
When checking or replacement is required, we
recommend a NISSAN dealer for servicing.
SDI2177
Check the fluid level in the reservoir.
The fluid level should be checked using the HOT
range (
*
1
: HOT MAX.,
*
3
: HOT MIN.) at fluid
temperatures of 122 to 1768F (50 to 808C) or
using the COLD range (
*
2
: COLD MAX.,
*
3
:
COLD MIN.) at fluid temperatures of 32 to 868F
(0 to 308C).
If the fluid is below the MIN line, add Genuine
NISSAN PSF or equivalent. Remove the cap
and fill through the opening.
CAUTION
. Do not overfill.
. Use Genuine NISSAN PSF or
equivalent.
CONTINUOUSLY VARIABLE
TRANSMISSION (CVT) FLUID
POWER STEERING FLUID
Maintenance and do-it-yourself 8-11
