T (Vehicle Information): Press this button to display
the oil life, units, tire pressure readings for vehicles
with the Tire Pressure Monitor System (TPMS),
engine hours, Tire Pressure Monitor System (TPMS)
programming for vehicles with the TPMS and without
a Remote Keyless Entry (RKE) transmitter, compass
zone and compass calibration on vehicles with this
feature, and RKE transmitter programming.
U (Customization): Press this button to customize
the feature settings on your vehicle. See DIC Vehicle
Customization
on page 4‑53
for more information.
V (Set/Reset): Press this button to set or reset certain
functions and to turn off or acknowledge messages on
the DIC.
Trip/Fuel Menu Items
3
(Trip/Fuel): Press this button to scroll through the
following menu items:
Odometer
Press the trip/fuel button until XX km (mi) displays.
This display shows the distance the vehicle has been
driven in either kilometers (km) or miles (mi).
Trip Odometers
Press the trip/fuel button until A or B displays. This
display shows the current distance traveled in either
kilometers (km) or miles (mi) since the last reset for
each trip odometer. Both trip odometers can be used
at the same time.
Each trip odometer can be reset to zero separately by
pressing the set/reset button while the desired trip
odometer is displayed.
The trip odometer has a feature called the retro-active
reset. This can be used to set the trip odometer to the
number of miles (kilometers) driven since the ignition
was last turned on. This can be used if the trip
odometer is not reset at the beginning of the trip.
To use the retro-active reset feature, press and hold
the set/reset button for at least four seconds. The trip
odometer will display the number of kilometers (km) or
miles (mi) driven since the ignition was last turned on
and the vehicle was moving. Once the vehicle begins
moving, the trip odometer will accumulate mileage.
For example, if the vehicle was driven 8 km (5 miles)
before it is started again, and then the retro-active reset
feature is activated, the display will show 8 km (5 miles).
As the vehicle begins moving, the display will then
increase to 8.1 km (5.1 miles), 8.2 km (5.2 miles), etc.
4-38
