OVERVIEW
4
1.4 INSTALLATION GUIDE
1.4.1 Quick Start Guide
The
Monitor Station Remote Installation
disc included with your Monitor Station Remote
is the same installation disc included with the FireStudio. (These installation files are also
downloadable from our Web site at www.PreSonus.com
.)
Before connecting your Monitor Station Remote to your FireStudio, you must install the
latest drivers and software for your FireStudio. It is very likely you already completed
these steps during your FireStudio installation. If you meet the following conditions, you
can skip to “Hardware Installation” and begin using your Monitor Station Remote:
9 You have already installed your FireStudio.
9 The version number of the FireStudio Installation Drivers disc used to install your
FireStudio is current with or later than the version number of the Monitor Station
Remote Installation disc included with your Monitor Station Remote.
9 The FireStudio Control Console Hardware Settings tab includes a section labeled
“MSR Settings”.
Hardware Installation
1) Connect one end of the supplied Ethernet cable to the
Remote Control Input
jack on
your FireStudio’s rear panel.
2) Connect the other end of the supplied Ethernet cable to the
Remote
input jack on
your Monitor Station Remote’s rear panel.
The lights on your Monitor Station
Remote should flash during this step.
3)
See “3 Sample Hookup Diagrams” for help with your speaker connections.
