Instrument cluster
Function Page
:
Coolant temperature gauge 112
? Coolant temperature
warning lamp
263
;
Speedometer with:
# Left turn signal
indicator lamp
J Brake warning lamp,
Canada only
255
÷ ABS/ESP
®
warning
lamp (Version 1)
4
258
d ABS/ESP
®
warning
lamp (Version 2)
4
260
Ò Distronic indicator
lamp (white) or distance
warning lamp (red)
5
135,
262
$ Brake warning lamp,
USA only
255
! Right turn signal
indicator lamp
Function Page
=
Left multifunction display
with:
Outside temperature
indicator or digital
speedometer (depending
on selected setting in the
control system)
116,
122
Main odometer 114
Set speed for cruise control
or Distronic
130,
136
?
Reset button for:
Trip odometer 113
Settings 121
Adjusting instrument
cluster illumination 112
4
Depending on vehicle production date.
5
Vehicles without Distronic: Warning/indicator lamp without function. It illuminates when the ignition is
switched on. It should go out when the engine is running.
30
Instrument cluster
At a glance
