Engine GL 550
Engine, type
273
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
8
Bore
3.86 in (98.00 mm)
Stroke
3.56 in (90.50 mm)
Total piston
displacement
333.2 cu in
(5 461 cm
3
)
Compression
ratio
10.7:1
Output acc. to
SAE J 1349
30
382 hp/6 000 rpm
(285 kW/6 000 rpm)
Maximum torque
acc. to SAE J 1349
391 lb-ft/
2 800 - 4 800 rpm
(530 Nm/
2 800 - 4 800 rpm)
Maximum engine
speed
6 500 rpm
Firing order
1-5-4-2-6-3-7-8
Poly-V-belt
2 398 mm
Electrical system GL 550
Alternator
14 V/180 A
Starter motor
12 V/1.4 kW
Battery
12 V/95 Ah
Spark plugs, type
NGK PLKR 7A
Electrical system GL 550
Spark plugs,
electrode gap
0.031 in (0.8 mm)
Spark plugs,
tightening torque
15 - 18 lb-ft
(20 - 25 Nm)
Main dimensions GL 550
Overall vehicle
length
200.8 in (5 101 mm)
Overall vehicle
width
31
83.6 in (2 124 mm)
Overall vehicle
height
72.4 - 75.6 in
(1 840 - 1 920 mm)
32
72.4 - 76.8 in
(1 840 - 1 950 mm)
33
Wheelbase
121.1 in (3 075 mm)
Track, front
66.3 in (1 683 mm)
34
Track, rear
66.5 in (1 688 mm)
34
Ground clearance
8.0 - 10.9 in
(202 - 277 mm)
32
8.0 - 12.1 in
(202 - 307 mm)
33
Turning circle
39.7 ft (12.1 m)
Weights GL 550
Roof load
max. 198 lb (90 kg)
30
Premium fuel required. Performance may vary with fuel octane rating.
31
Exterior rear view mirrors folded out.
32
Depending on the set vehicle level (vehicles without enhanced off-road package).
33
Depending on the set vehicle level (vehicles with enhanced off-road package).
34
21" wheels.
364
Vehicle specification GL 550 (164.886)
