Engine E 350 4MATIC
Output acc. to
SAE J 1349
27
268 hp/6 000 rpm
(200 kW/6 000 rpm)
Maximum torque
acc. to SAE J 1349
258 lb-ft/
2 400 - 5 000 rpm
(350 Nm/
2 400 - 5 000 rpm)
Maximum engine
speed
6 500 rpm
Firing order
1-4-3-6-2-5
Poly-V-belt
2 392 mm
Electrical system E 350 4MATIC
Alternator
14 V/180 A
Starter motor
12 V/1.4 kW
Battery
12 V/70 Ah
Spark plugs, type
Bosch Y 7 MPP33
Spark plugs,
electrode gap
0.031 in (0.8 mm)
Spark plugs,
tightening torque
15 - 18 lb-ft
(20 - 25 Nm)
Main dimensions E 350 4MATIC
Overall vehicle
length
191.9 in (4 874 mm)
Overall vehicle
width
28
81.5 in (2 071 mm)
Overall vehicle
height
57.8 in (1 467 mm)
Wheelbase
113.1 in (2 874 mm)
Track, front
62.2 in (1 580 mm)
Track, rear
63.0 in (1 599 mm)
Main dimensions E 350 4MATIC
Ground clearance
4.1 in (104 mm)
Turning circle
36.9 ft (11.3 m)
Weights E 350 4MATIC
Roof load
max. 220 lb (100 kg)
Trunk load
max. 220 lb (100 kg)
Vehicle specification E 550 (212.072)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz Center for the corresponding data of all
special bodies and special equipment.
Engine E 550
Engine, type
273
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
8
Bore
3.86 in (98.00 mm)
Stroke
3.56 in (90.50 mm)
Total piston
displacement
333.2 cu in
(5 461 cm
3
)
Compression
ratio
10.7:1
Output acc. to
SAE J 1349
29
382 hp/6 000 rpm
(285 kW/6 000 rpm)
Maximum torque
acc. to SAE J 1349
391 lb-ft/
2 800 - 4 800 rpm
(530 Nm/
2 800 - 4 800 rpm)
Maximum engine
speed
6 500 rpm
27
Premium fuel required. Performance may vary with fuel octane rating.
28
Exterior rear view mirrors folded out.
29
Premium fuel required. Performance may vary with fuel octane rating.
350
Vehicle specification E 550 (212.072)
Technical data
