Engine E 350 BlueTEC
Engine, type
642
Mode of operation
Diesel 4-stroke
engine
No. of cylinders
6
Bore
3.27 in (83.00 mm)
Stroke
3.62 in (92.00 mm)
Total piston
displacement
182.3 cu in
(2 987 cm
3
)
Compression
ratio
16.5:1
Output acc. to
SAE J 1349
210 hp/3 400 rpm
(157 kW/3 400 rpm)
Maximum torque
acc. to SAE J 1349
400 lb-ft/
1 600 - 2 400 rpm
(543 Nm/
1 600 - 2 400 rpm)
Maximum engine
speed
4 500 rpm
Firing order
1-4-2-5-3-6
Poly-V-belt
2 035 mm
Electrical system E 350 BlueTEC
Alternator
14 V/180 A
Starter motor
12 V/2.0 kW
Battery
12 V/95 Ah
Main dimensions E 350 BlueTEC
Overall vehicle
length
191.9 in (4 874 mm)
Overall vehicle
width
25
81.5 in (2 071 mm)
Main dimensions E 350 BlueTEC
Overall vehicle
height
26
57.8 in (1 467 mm)
Wheelbase
113.1 in (2 874 mm)
Track, front
62.2 in (1 580 mm)
Track, rear
63.0 in (1 599 mm)
Ground
clearance
26
3.5 in (89 mm)
Turning circle
36.9 ft (11.3 m)
Weights E 350 BlueTEC
Roof load
max. 220 lb (100 kg)
Trunk load
max. 220 lb (100 kg)
Vehicle specification E 350 4MATIC
(212.087)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz Center for the corresponding data of all
special bodies and special equipment.
Engine E 350 4MATIC
Engine, type
272
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
6
Bore
3.66 in (92.90 mm)
Stroke
3.39 in (86.00 mm)
Total piston
displacement
213.5 cu in
(3 498 cm
3
)
Compression
ratio
10.7:1
25
Exterior rear view mirrors folded out.
26
Data apply to unladen vehicle with standard equipment. Data may vary in vehicles equipped with AIRMATIC
depending on the selected damping settings and the current vehicle level.
Vehicle specification E 350 4MATIC (212.087)
349
Technical data
