546
Practical hints
Fuses
Fuse box in passenger compartment
The fuse box is located behind a cover in
the dashboard on the front passenger side.
1 Cover
Opening
̈ Open the front passenger door.
̈ Open the glove box (୴ page 316).
̈ Insert flat, blunt object as a lever into
the edge of the cover 1 at the position
indicated by the arrow.
̈ Loosen cover 1 from dashboard using
lever.
̈ Using your hands, pull cover 1 out
and remove.
Closing
̈ Hook cover 1 into the opening at the
front.
̈ Press cover 1 back on until it engag-
es.
Emergency engine shut-down
If the engine cannot be turned off as de-
scribed in the “Getting started” section
(
୴ page 69), you may use the following
emergency procedure.
̈ Take the fuse chart from the vehicle
tool kit (
୴ page 496).
̈ Open the fuse box in engine compart-
ment (
୴ page 545).
̈ Use the fuse extractor to remove
fuse 120. Find its location in the fuse
chart.
!
Do not use sharp objects such as a screw-
driver to open the fuse box cover 1 in the dash-
board, as this could damage the fuse box cover
or the dashboard.
