Replacing tail lamp/turn/backup lamp bulbs — F650 SuperCrewzer
only
The tail lamp/backup lamp bulbs are
located in the same portion of the
tail lamp assembly, one just below
the other. Follow the same steps to
replace either bulb:
1. Make sure the headlamp switch is
in the OFF position and then
remove the two screws holding the
light cover to the light housing.
2. Carefully pull away the lamp
cover.
3. Twist the bulb 1/8 of a turn
counter clockwise and remove it from the socket.
4. Pull the bulb straight out and push the new bulb in.
5. Turn the bulb clockwise to secure in place.
6. Replace the tail lamp cover and secure with the two screws.
Replacing foglamp bulbs (if equipped)
1. Make sure the headlamp switch is
in the OFF position and then
remove the bulb socket from the
foglamp by turning
counterclockwise.
2. Disconnect the electrical connector from the foglamp bulb.
3. Connect the new foglamp bulb to the electrical connector.
4. Install the bulb socket in the foglamp by turning clockwise.
Lights
67
