The relays are coded as follows:
Fuse/Relay
Location
Fuse Amp
Rating
Description
1 30A** Trailer Tow Run Feed
2 30A** Trailer Tow Park/Marker Lamps
3 30A** Trailer Tow Stop Lamps
4 30A** Trailer Tow Turn/Stop Lamps
5 — Not Used
R1 — Trailer Tow Run Relay
R2 — Trailer Tow Stop Lamp relay
R3 — Trailer Tow Park/Marker Lamp
Relay
R4 — Trailer Tow Park/Marker Lamp
Relay
R5 — Not Used
R6 — Not Used
R7 — Trailer Tow Left Turn/Stop Lamp
Relay
R8 — Trailer Tow Right Turn/Stop Lamp
Relay
** Maxi Fuse
Roadside Emergencies
160
