Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
29 10A Cluster, GEM, 7.3L Power Stroke
PCM (clutch switch input), APCM
(7.3L Power Stroke only),
Overhead console (SuperCrewzer
only), Keyless entry module
(SuperCrewzer only), Traxx
(Fuel) module (SuperCrewzer
only)
30 30A 7.3L Power Stroke PCM diode,
7.3L Power Stroke fuel heater
31 15A Allison MD Transmission, Neutral
start relay and PCM (7.3L Power
Stroke only)
Relay 1 — Interior lamps
Relay 2 — Not used
Relay 3 — Horn
Relay 4 — One touch down power window
Relay 5 — Not used
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the power distribution box before
reconnecting the battery or refilling fluid reservoirs
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and specifications chapter.
Roadside Emergencies
155
