PERIODIC MAINTENANCE
PERIODIC MAINTENANCE
Chain Adjustment
Adjustment of Front and Rear Shocks
There are five adjustable positions on each shock. The default position is in the middle set by
manufacture. Use a round nut wrench as you adjust the shock, the tension of shock spring will
increase as you screw to left, decrease as you screw to the right. Adjust according to the
weight of the riders.
STORAGE
In the event your vehicle is not to be operated for a period in excess of 30 days and at the end of riding
season prepare for storage as follows:
WARNING - Do not drain fuel while engine is hot. Be sure to move vehicle outside before draining fuel.
1. Drain fuel tank and remove all fuel remaining in the tank by using a suction device or by soaking up the fuel
with a clean rag or towel. Remove all fuel remaining in the carburetor by allowing engine to run out of fuel. Do not
perform any fuel removal procedure while smoking or near an open flame. Dispose of any rags or towels proper-
ly.
2. Lubricate engine cylinder by removing the spark plug and pouring an ounce of lean lubricating oil through the
spark plug hole into the cylinder. Crank the engine slowly to spread oil and replace spark plug.
3. Do not save or store gasoline over winter. Using old gasoline that has deteriorated from storage will cause hard
starting and affect engine performance.
4. When the vehicle is removed from storage re-read the owner’s manual, perform any assembly required, and
perform a pre-ride inspection. See Pre-Ride Inspection section of this manual.
Loosen the jam nuts
Turn adjustment nut clockwise
to remove deflection in chain
Leave 3/8 - 3.4 in. deflection in
chain. Tighten jam nuts to 40ft /
lbs.
29
