6
• If initial service is required, which results in the removal of the outer protective cover, removal must only be
performed by factory-trained personnel.
Caution: Use of other than the described user and calibration tools or other procedures may result
in exposure to hazardous laser light.
Caution: Using different than described at the HV101 user guide, may result in unsafe operation.
.
COMPONENTS
1 Power Button
2 Battery LED
3 Manual/Standby Button
4 Leveling LED
5 Manual/HI-Warning LED
6 Up and Down Arrow Buttons
7 Left and Right arrow Buttons
8 Zone-Scan Button
9 Rotation Control Button
10 Infrared-receiver for remote control
11 Rotor/Beam Exit
12 Cross Mark Notches
13 Handle
14 Battery compartment/door
15 5/8x 11 Tripod Mounts
16 Rubber feet
How to Use the Laser System
Powering the Laser
Batteries
Installing Batteries
Open the battery door using your fi ngers, a coin or a screwdriver.
Insert batteries into the housing so that the negative poles are on the bigger battery spiral spring.
Push down on the battery door until the latch “clicks” into position.
Laser Setup
Position the laser horizontally or vertically (tripod mount and rubber feet downward!) on a stable platform, wall
mount or tripod at the desired elevation. The laser recognizes automatically whether it is used horizontally or
vertically when switched on.
Turning On/Off the Laser
Press the power button 1 to turn on the laser.
Note: The laser always powers up in the automatic self-leveling mode. The LEDs (2, 4 and 5) are
turned on for 2 seconds.
The laser is level when the leveling indicator 4 is no longer fl ashing (once every second).
For the fi rst fi ve minutes after the laser self levels, the LED 4 lights solid then fl ashes every four seconds to
let you know the laser is still level.
After turning on the laser and after self-leveling, the laser starts in the last chosen mode. The „set and forget“
function turns on the laser beam while scan size, beam position and rotation speed are adjusted.
If the laser is positioned beyond it´s self-leveling range of ±8%, the laser beam, and manual and leveling
indicators fl ash simultaneously. Turn the unit off, reposition the laser within the self-leveling range and turn
it on again.
Note: If the laser is out of its self-leveling range and remains out of it for more than 10 minutes, the
unit shuts down completely.
Note: After the laser has been level for more than 5 minutes in horizontal mode and the rotor is
rotating at 600 rpm, the HI (height of instrument) alert activates. If the laser is disturbed (tripod
bumped, etc.) so that when it re-levels the laser beam elevation changes by more than 3 mm
(1/8 in.), the HI alert shuts down the laser and rotor, and the red LED fl ashes two times per second
(twice the manual-mode rate). To restore level, turn the laser off and on. After the laser has re-leveled,
check your initial reference elevation.
In order to switch the laser off, press the power button again.
