WARNING
● Do not use the HomeLinkா Universal
Transceiver with any garage door
opener that lacks safety stop and re-
verse features as required by federal
safety standards. (These standards be-
came effective for opener models
manufactured after April 1, 1982). A ga-
rage door opener which cannot detect
an object in the path of a closing garage
door and then automatically stop and
reverse, does not meet current federal
safety standards. Using a garage door
opener without these features in-
creases the risk of serious injury or
death.
● During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people or
objects are clear of the garage door,
gate, etc. that you are programming.
● Your vehicle’s engine should be turned
off while programming the HomeLinkா
Universal Transceiver.
PROGRAMMING HOMELINKா
1. With the ignition key in the OFF position,
press and hold the two outside buttons, and
release when the indicator light begins to
flash (after 20 seconds). This procedure
erases the factory set default codes and
does not haveto be followed whenprogram-
ming additional hand-held transmitters.
2. Hold the end of the hand-held transmitter
(from the device you wish to train) approxi-
mately1-3inches (26 - 76 mm) away from
the surface of HomeLinkா keeping the indi-
cator light in view.
3. Using both hands, simultaneously push the
hand-held transmitter button and the de-
sired HomeLinkா button. Do not release the
buttons until step 4 has been completed.
NOTE:
Some garage door openers may require the
procedures noted under “Canadian Pro-
gramming.”
4. The HomeLinkா indicator will flash, first
slowly and then rapidly. When the indicator
light flashes rapidly, both buttons may be
released. The rapid flashing light indicates
the HomeLinkா Universal Transceiver has
been successfully programmed.
To program the remaining two buttons, follow
steps 2 through 4.
If , after repeated attempts, you do not success-
fully program the HomeLinkா Universal Trans-
ceiver to learn the signal of the hand-held trans-
mitter, refer to “Rolling Code Programming” later
in this section.
If you have any questions or are having difficulty
programming your HomeLinkா buttons, refer to
the HomeLinkா web site at: www.homelink.com
or call 1-800-355-3515.
WIC0291
Instruments and controls 2-43
