XTA FORCE / VELOCITY PROFILES (WITH AN OPERATING VOLTAGE OF 325 VD.C.)
S=series motor phases P=parallel motor phases
Page 24
Appendices ServoTube 38 Installation Guide
XTA3804S force/velocity
PEAK
CONTINUOUS
0
100
200
300
400
500
600
700
800
0 1 2 3 4 5
Velocity (m/s)
Force (N)
XTA3804P force/velocity
PEAK
CONTINUOUS
0
100
200
300
400
0 1 2 3 4 5
Velocity (m/s)
Force (N)
XTA3806S force/velocity
PEAK
CONTINUOUS
0
200
400
600
800
1000
1200
0 1 2 3 4
Velocity (m/s)
Force (N)
XTA3806P force/velocity
PEAK
CONTINUOUS
0
100
200
300
400
500
600
0 1 2 3 4 5 6
Velocity (m/s)
Force (N)
XTA3808S force/velocity
PEAK
CONTINUOUS
0
200
400
600
800
1000
1200
1400
1600
0 1 2 3 4
Velocity (m/s)
Force (N)
XTA3808P force/velocity
PEAK
CONTINUOUS
0
200
400
600
800
0 1 2 3 4 5
Velocity (m/s)
Force (N)
XTA3810S force/velocity
PEAK
CONTINUOUS
0
200
400
600
800
1000
1200
1400
1600
1800
2000
0 1 2 3
Velocity (m/s)
Force (N)
XTA3810P force/velocity
PEAK
CONTINUOUS
0
200
400
600
800
1000
0 1 2 3 4 5
Velocity (m/s)
Force (N)
Figure C.6 - XTA force / velocity profiles
