Displaying fuel consumption and
generated electric power
The COMAND display indicates the fuel
consumption and the generated electric
power for the last 15 minutes of driving.
X
Select Vehicle Q Hybrid Q
Consumption.
1
Fuel consumption
2
Generated electric power
Each bar in the chart represents the average
value for 1 minute.
Average fuel consumption 1 can differ from
the fuel consumption that is displayed in the
From Start submenu in the Trip menu.
Resetting values
The values are reset together when resetting
the trip computer in the From Start
submenu. Refer to the Operator’s Manual.
Driving and parking
Safety notes
G
Warning!
When your vehicle is in electric drive mode the
engine produces significantly lower noise
levels. Other motorists or pedestriants,
especially those who are visually or hearing
impaired, may be unable to hear your vehicle
while it is in motion. This is particularly true
when driving at lower speeds and during
parking maneuvers. At all times, it is the
responsibility of the driver to be aware of their
surroundings, especially in these low speed
situtations. Otherwise other road users could
be seriously or fatally injured.
G
Warning!
Make sure absolutely no objects are
obstructing the pedals’ range of movement.
Keep the driver’s footwell clear of all
obstacles. If there are any floormats or
carpets in the footwell, make sure the pedals
still have sufficient clearance.
During sudden driving or braking maneuvers
the objects could get caught between or
under the pedals. You could then no longer
brake or accelerate. This could lead to
accidents and injury.
Starting the engine
:
Green or yellow READY indicator lamp
X
Switch on the ignition.
X
Apply the brake pedal fully and release it to
activate the RBS.
The RBS is activated. For more information
on the RBS, see (Y page 10).
X
Observe the notes on “Starting the engine”
in the Operator’s Manual and start the
combustion engine.
The vehicle is operational when the green
or yellow READY indicator lamp : is
illuminated.
16
Controls in detail
