Instrument cluster
Function Page
:
÷ ABS/ESC warning
lamp
10,
24
;
$ Brake warning lamp,
USA only
24
J Brake warning lamp,
Canada only
24
=
é Recuperative Brake
System (RBS) warning lamp
24
?
Green or yellow READY
indicator lamp for the
HYBRID system 16
A
Multifunction display
with:
Charging level high-voltage
battery 15
Control system and COMAND
i
For information on the instrument cluster
control system and COMAND operation,
refer to the Operator’s Manual.
The current operating mode of the HYBRID
system can be displayed in the multifunction
display and in the COMAND.
The COMAND can also display a chart of the
fuel consumption and the electric power that
has been generated (Y page 16).
Selecting submenu in the
multifunction display
Use the buttons on the multifunction steering
wheel.
X
Press button = or ; to select the
Trip menu.
X
Press button 9 or : to select the
HYBRID menu.
Selecting submenu in the COMAND
display
X
Select Vehicle Q Hybrid Q Energy.
14
Controls in detail
