Specifications
Form No. 8R65-EA-03C
▼
Lubricant Quality
*Refer to the recommended SAE viscosity numbers on page 8-9.
▼
Capacities
(Approximate Quantities)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼
Dimensions
*
With license plate holder
Lubricant
Classification
API Service ILSAC
Engine oil
*
SL GF-III
Lubricant Classification
Manual transmission oil API Service GL-4 or GL-5 (SAE 75W-90)
Automatic transmission fluid ATF M-III or equivalent (e.g. Dexron® III)
Rear differential oil API Service GL-5 (SAE 90)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
Item
Unit
L US qt Imp qt
Engine oil
With oil filter replacement 3.5 3.7 3.1
Without oil filter replacement 3.3 3.5 2.9
Coolant 9.8 10.4 8.6
Manual transmission oil 1.75 1.8 1.5
Automatic transmission fluid 8.7 9.2 7.7
Rear differential oil 1.3 1.4 1.1
Fuel tank 60 15.9 (US gal) 13.2 (Imp gal)
Item Model
Overall length
4,425 mm (174.2 in), 4,430 mm
*
(174.4 in)
Overall width 1,770 mm (69.7 in)
Overall height 1,340 mm (52.8 in)
Front tread 1,500 mm (59.1 in)
Rear tread 1,505 mm (59.3 in)
Wheelbase 2,700 mm (106.3 in)
