IMPORTANT! Use only a Power Wheels
®
6 volt lead-acid
rechargeable battery. Use of any other battery will damage your
vehicle. Make sure that you charge the battery for at least 18 hours
using the enclosed Power Wheels
®
6 volt charger before operating
your vehicle for the first time. Charge the battery for at least 14
hours after each use of the vehicle. Never charge the battery
longer than 30 hours. Failure to follow these instructions may
damage your battery and will void your warranty.
C3493pr-0921
20
BATTERY INSTALLATION
I
• Push the battery retainer and fit the battery into the pocket.
• Release the battery retainer.
Battery Retainer
Battery
• Grasp the bottom edge of the grill and lift the hood.
• Remove the two screws in the pretend motor.
• Remove the pretend motor.
Pretend Motor
1
2
• Plug the motor harness connector into the battery connector. Push
firmly to make sure the connector is inserted properly.
Motor Harness
Connector
• Replace the pretend motor.
• Replace the two #8 x
3
/
4
" screws into the pretend motor
and tighten.
• Lower the hood and “snap” in place.
Pretend Motor
3
4
Battery Connector
