ASSEMBLY
F
C3493pr-0921
29
• Fit a side mirror to the side of the vehicle.
Side Mirror
• From the inside of the vehicle, insert two #8 x
3
/
4
" screws through the
vehicle and into the side mirror.
• Tighten the screws.
• Repeat Assembly steps 26 and 27 to assemble the other side mirror.
#8 x
3
/
4
" Screws
26
27
RIGHT SIDE VIEW
• Insert three #8 x
3
/
4
" screws into the windshield.
• Tighten the screws.
• Insert and “snap” the tabs at the top of the windshield into the slots
in the top edge of the vehicle.
Slots
Windshield
28
FRONT VIEW
