ASSEMBLY
F
17
C3493pr-0921
Hint: Before assembling the pretend engine, you may want to install
the battery. Please refer to page 20, steps 1 and 2.
• Fit the pretend engine into the front end of the vehicle.
• Insert two 1" bolts into the pretend engine.
• Tighten the screws.
• Fit a peg on the hood into a slot in the front end of the vehicle.
• Flex the hood slightly and then insert the other hood peg into the
other slot in the front end of the vehicle.
• Lower the hood. Push down near the front of the hood to “snap”
into place.
Pretend
Engine
Hood Peg
Slot
30
31
VEHICLE CARE
G
• Check all screws, cap nuts and their protective coverings regularly
and tighten as required. Check plastic parts on a regular basis for
cracks or broken pieces.
• During snowy or rainy weather, the vehicle should be stored inside
or under a protective cover. Remember to charge the battery at
least once per month while your vehicle is not in regular use.
• Avoid operating the vehicle in wet or snowy conditions, and do not
spray the vehicle with a hose. Do not wash the vehicle with soap
and water. Water or moisture in the motors or electrical switches
can cause them to corrode, and could cause switch or motor failure.
• Avoid operating the vehicle on sand, loose dirt or gravel. Sand,
loose dirt or gravel in the motors or electrical switches can cause
them to jam, and could cause switch or motor failure.
• The vehicle can be wiped down with a soft, dry cloth. For a shiny
finish, you can wipe plastic parts with a non-wax furniture polish
applied to a soft-cloth. Do not use automotive wax. Do not use
soap and water or spray the vehicle with a hose.
• To ensure that your vehicle stays in good operating order, we
recommend that you periodically have your vehicle checked by a
Power Wheels
®
authorized service center. For the location of the
authorized service center nearest you, please visit us on-line at
www.powerwheels.com or call 1-800-348-0751.
