KK6LBAS
License Plate Mount
and Light Cluster
(not available)
25
25
24
26
26
27
29
30
30
31
31
32
84
27
27
78
79
77
75
76
51
74
55
42
85
73
130
*70
*70
*70
*70
104
109
115
103
64
68
67
93
94
95
102
Left Fender
Left Winch Shown
15
14
13
10
9
4
12
19
20
20
22
16
18
17
23
21
7
6
12
11
8
3
5
1. 5432 1 Left Ratchet Winch Assembly (Plated)
2. 5433 1 Right Ratchet Winch Assembly (Plated)
3. 03569-95 1 Ratchet Frame
4. 03570-95 1 Left Spool Tube
- 03571-95 1 Right Spool Tube
5. 03577 1 Heavy Duty External Snap Ring
6. 03574-95 1 Ratchet Handle
7. 03668 1 18 Ga. Shim Washer
8. 03575-95 1 Left Ratchet Gear
- 03576-95 1 Right Ratchet Gear
9. 03666 1 5/16" x 1-1/4" Roll Pin
10. 02243 1 Black Vinyl Hand Grip
11. 05450 1 Winch Pawl
12. 01864 2 Winch Pawl Spring SS
13. 05449 1 Winch Pawl Bushing SS
14. 00059 1 3/8" Flatwasher
15. 05444 1 3/8"-16 UNC x 3/4" Hex Bolt w/epoxy Gr.5
16. 03572-95 1 Left Ratchet Pawl Arm
- 03573-95 1 Right Ratchet Pawl Arm
17. 03578 1 5/16"-18 UNC x 1/2" Shoulder Screw
18. 01998 1 5/16" Flatwasher SS
19. 02002 1 1/4" Flatwasher SS
20. 02772 2 1/4"-20 UNC Nylon Locknut
21. 04055 1 1/4"-20 UNC x 1" Hex Hd. Bolt Gr.5
22. 00214 1 1/4" Flatwasher
23. 05337 1 Lock Pin w/Cable
- 5192 License Plate Light and Light Cluster
24. 04505-25 1 License Plate and Light Cluster Bracket
25. 04176 4 1/4"-20UNC x 3/4" Carriage Bolt
26. 02519 2 1/4"-20UNC x 1/2" Slotted Truss Head Bolt
27. 02163 1 Square License Plate Light w/washer and nut
- 02164 - Clear License Plate Light LENS ONLY
REF. PART
NO. NO. QTY. DESCRIPTION
28
91
92
5
3
87
