Model DA66 ACTUATOR PARTS BREAKDOWN
- 8606701 1 DA66 Brake Actuator complete (incl. ref. 1-25)
- 5400 - Lever Replacement Kit (incl. items w/*)
- 5398 - Master Cylinder Repair Kit w/ gasket
- 5495 - Coupler Repair Kit
ACTUATOR PARTS LIST
Please order replacement parts by PART NO. and DESCRIPTION.
REF. PART
NO. NO. QTY. DESCRIPTION
2
24
6
6
22
23
2
21
1
11
12
7
7
5
10
10
2
2
3
18
19
19
13
15
16
20
20
14
8
9
4
17
1. 07599-95 1 6000# 2" Ball Coupler
2. SB23278 4 Roller
3. 05957-95 1 Front Roller Spacer
4. 02166 1 3/8"-16UNC x 2-3/4" Hex Head Bolt (gr.5)
5. 07176 1 3/8" Stover Lock Nut
6. 05684 2 1/2"-13UNC x 4-1/2" Hex Head Bolt (gr.5)
7. 02178 2 1/2"-13UNC Nylon Insert Lock Nut
8. 05959 1 Push Rod Assembly
9. 05692 1 Damper/ Shock
10. 05958-95 2 Rear Roller Spacer
11. *05951 1 Emergency Lever
12. 05955-95 1 Front Cover
13. *SB24700 1 2' Cable with S-Hooks
14. SB10555 2 Replacement S-Hook ONLY
15. 05960 2 5/16"-18UNC x 1/2" Self-Tapping Screw
16. 05424 2 5/16" External Tooth Lock Washer
17. *05693-95 1 Emergency Lever Spring
18. 03876 1 Master Cylinder Cap w/ diaphragm & O-ring
19. 01076 4 1/4-20UNC x 3/4" Hex Head Bolt
20. 00057 4 1/4" Lock Washer
21. 03564-95 1 Outer Case
22. 05681 1 Replacement Master Cyl. Gasket ONLY
23. 05680 1 Master Cylinder with gasket 05681 X
24. SB12098 1 1/8" pipe - 3/6" inverted Flare Fitting
25. 05966-95 1 Back Cover
25
5495
Coupler Repair Kit
for
6000 lb.
coupler
5398 Master Cylinder Repair Kit
(gasket included)
