Page 22
1. 00059 4 3/8" Flatwasher
2. 02592 8 3/8"-16UNC Nylon Insert Locknut
3. 01888-25 1 Tool Box
4. 00182 1 Small Hair Pin
5. 02742-25 2 Mounting "Z" Bracket
6. 00907 4 3/8"-16UNC x 1" Hex Head Bolt (gr.5)
7. 02759 2 3/8"-16UNC x 3" Square U-Bolt
OPTIONAL WINCH
KK2TB 1 Optional Tool Box
OPTIONAL TOOL BOX
PARTS LIST
1
2
3
4
7
5
7
6
2
3
5
6
7
7
1
4
Please order replacement parts by PART NO. and DESCRIPTION.
* All options may not mount on tow dolly simultaneously.*
OPTIONAL SPARE TIRE and MOUNT PARTS BREAKDOWN
REF.
NO. PART NO. QTY. DESCRIPTION
PARTS LIST
KK2W 1 Optional Winch
Please order replacement parts by PART NO. and DESCRIPTION.
1. 04620 1 Winch Mechanism (1400 capacity)
- 04621 - Replacement Handle
3. 01738 1 Strap Assembly (includes strap & hook)
4. 02207 1 3/8"-16UNC x 3" Hex Hd. Bolt (gr.5)
5. 02769 2 3/8"-16UNC x 4" Hex Head Bolt (gr.5)
6. 00059 2 3/8" Flatwasher
7. 02592 3 3/8"-16UNC Nylon Insert Locknut
* All options may not mount on tow dolly simultaneously.*
3. 02193-25 1 Spare Tire Bracket
4. 02917 1 Stud Bolt (12mm x 1.5)
5. 02933 2 Wheel Nut (12mm) Chrome
6. 02759 2 3/8"-16UNC Square U-Bolt
7. 00059 2 3/8" Flatwasher
8. 02592 4 3/8"-16UNC Nylon Insert Locknut
KK6STM 1 Spare Tire Mounting Bracket
1. N/A 1 ST205/75R 14"x"C" BSW Radial Tire
2. 04367 1 6" x 14" Rim 115mm Bolt Circle
- KK8STBR 1 Optional Spare Tire and Rim
- KK6TC Optional Spare Tire Cover
Please order replacement parts by PART NO. & DESCRIP-
Drive in stud here for
tire with rim #04173 X
(100mm bolt circle).
Drive in stud here for
tire with rim #04366
(115mm bolt circle).
2
3
7
8
6
* All options may not mount on tow dolly simultaneously.*
5
1
4
