P. 14 User Guide AS-6070 TW
Priority Door Access
(Enabled by default.) If the Remote Door Locks option is installed on your vehicle, this safety
feature allows you unlock solely the driver’s door with a single press of the
UNLOCK button on the
transmitter; upon a second press of the
UNLOCK button, all the other doors will unlock.
Active or Passive Arming
(Passive Mode by default.) The alarm and Starter Kill can be configured either to Passive Mode (so
as to arm automatically) or Active Mode (so as to require user intervention for arming). By default,
your System is configured to Passive Mode. In Passive Mode, the alarm and Starter Kill will
automatically arm 30 seconds after the last door is closed. The System will not arm if a door is left
open, or if you re-open a door within the 30-second delay.
Important note: When the System re-arms automatically or if there is an alarm condition, you
can disarm the When the System by simply pressing the UNLOCK button.
The Starter Kill and the Anti-grind Feature
With this added security feature, the system will prevent your vehicle from starting with the ignition
key when the Starter Kill is armed. If your System was installed with the Starter Kill option, one will
not be able to start your vehicle with the key unless the system has been unlocked and disarmed
first, or put into Valet Mode.
Note: If the Starter Kill is installed, your vehicle will benefit from a protection against starter
motor damage that could occur after remote-starting the engine should the user, by force of
habit, turn the ignition key to the CRANK position.
Shock Sense, Warn-away Sense
(Both enabled by default.) Your System will react to a full shock by triggering the alarm; it can also
respond to a lighter shock (30 % of the strength of a full shock) by giving a warn-away (without
triggering an alarm condition). When the engine is running after a remote start, however, the
System will prevent any alarm condition to be triggered ; it will still give a warn-away if this
feature has not been disabled at installation.
Note: After a remote start, although the shock sensor is disabled, all the other alarm-
triggering zones, such as the doors or the hood, may still trigger an alarm.
Disarmed Notification
(Off by default.) This feature will notify the user when the vehicle was left disarmed: after the
engine is shut down (with the key removed) and all doors are closed, the siren will chirp once after
a 10-sec. notification delay to warn the user that the vehicle was left unprotected. The notification
can be avoided by pressing the
LOCK or UNLOCK button on the transmitter.
The user will likewise be notified after the System is disarmed using the transmitter.
Siren or Horn Chirps
(
ON by default.) The siren will chirp to confirm basic operations on the System:
x By default, upon locking the doors the siren will give one chirp if no protection zone is active.
x If a zone is active as the doors are being locked, the siren will give three chirps.
x When the doors are being unlocked, the siren will give two chirps if no intrusion was detected.
x If an intrusion was detected, as the doors are being unlocked the siren will give four chirps.
The system can alternatively be set to:
Warning Mode: no chirp during lock/unlock…
x unless a zone is active when locking, in which case there will be 3 chirp upon locking
x or unless the alarm was triggered, in which case there will be 4 chirps when unlocking);
Open Zone Notification Mode: 3 warning chirps if a door is left open 10 sec. after arming.
No Chirp: the siren will not chirp under any circumstance.
