Make absolutely sure that you adhere to
the specified folding order when fully
enlarging the cargo compartment:
R
fold down the center seat in the 2nd row
of seats (7-seat vehicles)
R
fold down the outer seats in the 2nd row
of seats
R
fold down the seats in the 3rd row of
seats
You could otherwise damage the seats.
Folding down the center seat in the 2nd
row of seats
!
Close the cup holder in the 2nd row of
seats before folding down the 2nd row of
seats. You could otherwise damage the
seats or cup holder.
X
Lower the head restraint on the center seat
in the 2nd row of seats fully (Y page 102).
X
Pull release loop : in the direction of the
arrow.
X
Fold backrest ; forwards completely until
it is resting on seat cushion = (armrest
position).
Armrest position
X
Pull release loop ? in the direction of the
arrow and hold it securely.
The seat is released and folds up.
X
Press seat A further down until the front
of the seat engages in the trunk floor
position.
Trunk floor position
Folding down the outer seats in the 2nd
row of seats
!
If you want to fold the outer seats down
in the 2nd row of seats, the front seats must
not be in the rearmost position. Otherwise,
you could damage the front seats and outer
seats in the 2nd row.
!
Close the cup holder in the 2nd row of
seats before folding down the 2nd row of
seats. You could otherwise damage the
seats or cup holder.
X
Move the seat concerned in the 2nd row to
its rearmost position (Y page 103).
X
Remove the center console for the 2nd row
of seats, if installed (Y page 249).
252
Stowage areas
Loading, stowing and features
