-6.9-
[FUNC MENU]
1. FUNC1 OFF ON
2. FUNC2 OFF ON
3. FUNC3 OFF ON
4. FUNC1 SET
5. FUNC2 SET
6. FUNC3 SET
7. F.2 SET
1. ↑
2.
FUNC SEL CST OCEAN R-SEA FLT BY
HBR L RAIN
3. ECHO AVG OFF 0.5 1 2 3
4. INT REJ OFF 1 2 3
5. STRETCH OFF 1 2 3
6. N REJ OFF ON
7. ENHANCE OFF ON
8. CONTRAST 1 2 3
9. A/C AUTO OFF ON
0. PULSE
[PLOT MENU 1]
1. MARK DISP OFF ON
2. ERASE
3. VECT REF RELTRUE
4. VECT TIME 30sec 1 3 6 15 30min
5. CPA SET
OFF 0.5 1 1.5 2 3 4 5 6NM
6. TCPA SET
30sec 1 2 3 4 5 6 12 15min
7. TRACK OFF ON
8. AUDIO ALARM OFF ON
9. INTVAL 30sec 1 2 3 6min*
0. ↓*
[MARK MENU]
1. ERASE
2. MODE REL TRUE
[PLOT MENU 2]*
1. ↑
2. AUTO ACQ OFF ON SET
3. GUARD ZONE OFF ON SET
4. TRACK TEST OFF ON
5. LAND DISCRIM 0 1 2 3 4
6. TTM OFF REL TRUE
7. VECT START 1min 20SCAN
8. REF TGT VECTOR OFF ON
9. TARGET BASED SPEDD
[F.2 MENU]
Select by VRM knob
and press ENTER key.
1. TRAIL TIME 21. SART
2. TRAIL MODE 22. WATCH TIME
3. TRAIL SHADE 23. STERN MARK
4. TRAIL LEVEL 24. OS MARK
5. ALARM AREA 25. TUNE A/M
6. ALARM MODE 26. EXT WP
7. TGT COLOR 27. OS POSN
8. ECHO AVG 28. CLTR SWEEP
9. INT REJ 29. P MONITOR
10. ECHO STRETCH 30. EBL/+/PI
11. NOISE REJ 31. VRM/+ RNG*
12. ECHO ENHANCE
13. 2ND ECHO
14. CONTRAST
15. PLOT MENU
16. MARK MODE
17. BRILL MENU
18. DRIFT MENU
19. NAV DATA
20. DISPLAY
* Requires Auto Tracking Aid ARP-17 (Option).
RADAR MAP menu
Without RP-17
With RP-17
Displayed only in stand-by. * R-type only.
1. ↑
2. 0.5NM S1 S2
3. 0.75-1.5NM S1 S2 M1
4. 3NM S1 S2 M1 M2 M3
5. 6-12NM M1 M2 M3 L
6. 24NM M2 M3 L
1. Mark Selection
2. MOB
3. Display On Off
4. Mark Color RED CYN PPL WHT
5. Position Correction
1. ↑
2. Position Corr. No Yes
3. Delta L/L Entry
4. Variation Corr. Off Manu. Auto
5. Manual Entry
When preeing [8] key for chart overly with
RP-17 equipped
Requires Video Plotter RP-17.
(Continued on next page)
[MENU] key +
[7]
[6]
[8]
[4],
[5],
[6]
[7]
[0]
[5]
[0]
B
C
