-1.2-
1.3 Control Description
TLL: Target Latitude/Longitude outputted in IEC 61162-1 format.
VRM
OFF
ON
DEGAUSS (PUSH)
EBL
OFF
ON
BRILL A/C RAIN A/C SEA
GAIN
DIMMER
HL OFF (PUSH)
A/C AUTO (PUSH)
TLL (PUSH)
DAY/NIGHT (PUSH)
BKGND
COLOR
AUDIO
OFF
RINGS
FUNCT
ION
RANGE
+
-
TX
STBY
DIRECT ACCESS CONTROL PANEL
MENU ACCESS CONTROL
PANEL
1
2
3
4
5
6
7
8
9
0
Function keys are also used as
numeral keypads for 0-9.
MODE
TGT
TRAIL
TGT
ALARM
SHIFT
ZOOM
INDEX
LINE
EBL
OFFSET
PLOT
SYMBOL
MARK
F1
F2
MENU
CANCEL
CLEAR
ENTER
SELECT
(RM), Head-up True Bearing (RM), Course-up
Press to select presentation mode - Head-up
(RM), North-up (RM), North-up (TM). Ref.
Target trails over selected time. Ref. 1.26.
Sets two target alarm zones. Ref. 1.22.
Off-centers the radar picture, turns on/off
Zoom (R-type) or manual-resets the TM
display. Ref. 1.23.
Controls Parallel Index Lines . Ref. 1.27.
Offset 1st EBL together with Cursor. Ref. 1.20.
Inscribes reference marks (Ref. 1.28) or
marks in Radar map (Ref. 1.47).
Selects functions of primary controls. Ref. 1.32.
Selects setting of one of parameters visible on
STBY. Ref. 1.33.
Primary menu containing: Video Plot, Target
Trail, Target Alarm, Watch Time, Echo Sig,
Function, Plot, Mark, Brill, Others. Ref. 1.6, etc.
Cancels entry, stops tracking.
Concludes entry of data, displays target data.
Enters EPA mark. Ref. 1.25.
Select FUNC 1, 2 or 3 which is a
setting of picture effecting parameters.
Ref. 1.34.
POWER
switch
