-1.31-
1.33 [F2] Key
The [F2] key selects the level or setting for one of the parameters as selected at step 3 below on the
STBY screen.
1.33.1 Presetting the [F2] key
1. In the STANDBY condition, press the [MENU] key.
2. Press the [6] key twice to display the FUNC menu.
FUNC
1. FUNC 1 OFF ON
2. FUNC 2 OFF ON
3. FUNC 3 OFF ON
4. FUNC 1 SET
5. FUNC 2 SET
6. FUNC 3 SET
7. F⋅2 SET
F2 SET option not valid in TX mode; valid on STBY only.
3. Press the [7] key twice to select F•2 SET. The following display appears:
[F2 MENU]
Select by VRM knob
and press ENTER key.
1. TRAIL TIME
2. TRAIL MODE
3. TRAIL SHADE
4. TRAIL LEVEL
5. ALARM AREA
6. ALARM MODE
7. TGT COLOR
8. ECHO AVG
9. INT REJ
10. ECHO STRETCH
11. NOISE REJ
12. ECHO ENHANCE
13. 2ND ECHO
14. CONTRAST
15. PLOT MENU
16. MARK MODE
17. BRILL MENU
18. DRIFT MENU
19. NAV DATA
20. DISPLAY
21. SART
22. WATCH TIME
23. STERN MARK
24. OS MARK
25. TUNE A/M
26. EXT WPT
27. OS POSN
28. CLTR SWEEP
29. P.MONITOR
30. EBL/+/PI
31. VRM/+ RNG
31. on R-type only
(This screen appears only in the STBY condition.)
4. Select function desired with the VRM rotary control.
5. Press the [ENTER/SELECT] key to register your selection, and then press the [MENU] key
to finish.
Then, a single press of [F2] turns on the function preprogrammed in the procedure above.
