2007 E-Series Wagon
E-SERIES WAGON
May 2006
E-Series Wagon
BODY DIMENSIONS — Wagon Interior
Model/Series E-150 E-350 Super Duty E-350
Super Duty
Extended
Code Description Inches Inches Inches
A Cargo Length at Belt 110.3 110.3 130.3
B Cargo Length at Floor 120.6 120.6 140.6
C Overall Width 79.3 79.3 79.3
D Cargo Width Between Wheelhouses 51.1 51.1 51.1
E Cargo Height 53.1 53.1 52.3
F Head Room (1st Row) 42.0 42.0 42.0
F Head Room (2nd Row) 40.2 40.2 40.2
F Head Room (3rd Row) 40.1 40.1 40.1
F Head Room (4th Row) — 38.9 39.6
F Head Room (5th Row) — — 37.4
G Leg Room (1st Row) 40.0 40.0 40.0
G Leg Room (2nd Row) 38.6 38.6 38.6
G Leg Room (3rd Row) 41.0 41.0 41.1
G Leg Room (4th Row) — 40.6 40.6
G Leg Room (5th Row) — — 38.0
H Shoulder Room (1st Row) 68.1 68.1 68.1
H Shoulder Room (2nd Row) 71.7 71.7 71.7
H Shoulder Room (3rd Row) 71.7 71.7 71.7
H Shoulder Room (4th Row) — 69.4 69.4
H Shoulder Room (5th Row) — — 67.5
I Hip Room (1st Row) 65.5 65.5 65.5
I Hip Room (2nd Row) 66.5 66.5 66.5
I Hip Room (3rd Row) 66.8 66.8 66.8
J Hip Room (4th Row) — 66.1 66.1
J Hip Room (5th Row) — — 65.8
A
E
G
B
F
C/I
H
J
D
Dimensions cont’d
