English
Controls and Display
The RDU link
indicators show the
the MDU is connected
to the RDU by the
wireless link.
The indicator changes
to show a lost
connection.
The IntelliMute
(I-Mute) symbol
shows only if the
feature is activated.
Symbol changes to
indicate if above or
below Set-point
when IntelliMute is
turned on.
(Refer to page 24.)
RDU Display
Standby Screen
When arrow is
displayed, you can go to
the next Standby Control
screens by pushing
MUTE/ button.
RDU battery icon displays
charge condition of RDU
battery. Sections change to
display battery level, or if
the battery is being charged.
City/Highway symbol
changes to indicate
activated alert filtering
mode.
GPS icon indicates
GPS satellite lock.
Icon changes to
indicate lost signal
condition.*
Compass indicator uses
GPSL to indicate direction of
travel.*
*Note: The GPS icon, Compass and other GPS features only display
if GPSL module is connected (optional for XRS R7, standard on
XRS R9G).
Your Detector
