Installation
8
English
1. Loosen MDU (gray) bracket
adjust knob.
2. Adjust module to a position
parallel to the road.
3. Tighten knob to set proper
horizontal detection
position. The MDU
mounting bracket has two
detent positions:
• one for detection
operation (horizontal
position)
• one for storage or
concealment (up
position). Makes MDU
less visible from outside.
IMPORTANT:
MDU
will not provide any
radar/laser detection in
“Stored/Concealed”
position.
Your Detector
Not In Use.
Stored/Concealed
Position.
Detection
Position
Lower to
Operating
Detection
Position.
Bracket
Adjust Knob
Loosen
Tighten
1
2
3
