120
Chapter 4 Ethernet Params Menu
Ethernet Params Menu
The ETHERNET PARAMS menu helps your printer communicate on a
network.
For information on assigning the IP Address, Gateway Address, Subnet
Mask, and MAC Address, refer to “Methods Of Adjusting Paper Position” on
page 145.
You may also enable or disable the Novell or NetBIOS Protocols within this
menu, as well as selecting which Novell Frame scheme is used in processing
Novell signals. See Chapter 10, “Novell Configuration” for more details.
If the printer is connected to the LineJet Printer Manager utility, the PPM Port
number and PPM Port Timeout settings must match the settings in the LineJet
Printer Manager program.
ETHERNET
PARAMS
IP Address
Gateway
Address
Subnet Mask
MAC Address
Novell
Protocol
NetBIOS
Protocol
xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx hhhhhhhhhhhh
Enable*
Disable
Enable*
Disable
Novell Frame
PPM Port
Number
PPM Port
Timeout
Ethernet 802.2*
802.2 Snap
Auto Sensing
Ethernet II
Ethernet 802.3
3001*
(0-65535)
100 secs.*
(1-255)
Ethernet
1
Speed
Auto Select*
10 Half Duplex
10 Full Duplex
100 Half Duplex
100 Full Duplex
* Factory Default
1
If you change the Ethernet speed setting,
you must also change the switch or hub
setting to match.
