Player SIS Commands
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Password and Security Settings
Set administrator
password
E X3#
CA
}
Ipa•
X3#] X3#
= Up to 12 alpha-numeric
characters.
View administrator
password
E
CA
}
Ipa****
]
Reset (clear)
administrator
password
E
•CA
}
Ipa•
]
Set user password E X3#
CU
}
Ipu•
X3#] X3#
= Up to 12 alpha-numeric
characters.
View user password E
CU
}
Ipu****
]
Reset (clear) user
password
E
•CU
}
Ipu•
]
View session security
level
E
CK
} X5@] X5@
= Security level of connection
11=user, 12=administrator.
File Commands
View disk free space
15I
M*N*O
]
Local storage details:
M=Block size (Bytes)
N=Free Inodes (returns -1 if
unlimited)
O=Free blocks
Change/create
directory
E
path/directory/CJ
}
Dirl path/directory/
] filename/date/time/length
Return to root
directory
E
/CJ
}
Dirl/
] filename/date/time/length
Up one directory E
../CJ
}
Dirl path/directory/
]
View current directory
E
CJ
}
path/directory/
]
space remaining/bytes left
Erase user-supplied
file
E
lenameEF
}
Del•path/lename
]
Erase current
directory and
included files
E
/EF
}
Ddl
] Also deletes files inside
directory
Erase current
directory and sub-
directories
E
//EF
}
Ddl
]
List files from current
directory
E
DF
}
filename•date/time•length
]
space_remaining•Bytes Left
]]
List files from current
directory and below
E
LF
}
path/filename•date/time•length
]
path/filename•date/time•length
]
path/filename•date/time•length
]
... space_remaining•Bytes Left
]]
NOTE: LF has same response from unit as DF command, except path / directory precedes filenames for files
from directories below the current directory.
Load file to user flash
memory
E
+UFlesize,lename
}
(followed by raw file data using
binary mode, if necessary)
Upl
] If there is insufficient space
to store the file, response is
Fld?.
Load file to user flash
and set specific time
and date
E
+UFlesize*<day>•<mo
nth>•<day>•<year>•<hour>
•<minute>•<second>,
lename
}
(followed by raw file data using
binary mode, if necessary)
Upl
]
If there is insufficient space
to store the file, response is
Fld?.
Retrieve file from user
flash memory
E
lenameSF
}
Response is 4 bytes
of file size plus the raw
unprocessed data in the file.
