Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional
Description
SNMP (Simple Network Management Protocol)
SNMP unit contact
Set unit contact
E
C
X60%
SNMP
}
Snmp C*
X60%]
Sets the unit contact
to
X60%
.
Set unit contact to
default
E
C
•
SNMP
}
Snmp C*Not•Specified
]
Sets the unit contact to the
default setting.
View unit contact
E
CSNMP
}
X60%] View the unit contact.
SNMP unit location
Set unit location
E
L
X60^
SNMP
}
Snmp L*
X60^]
Sets the unit location
to
X60^
.
Set unit location to
default
E
L•SNMP
}
Snmp L*Not•Specified
]
Sets the unit location to the
default setting.
View unit location
E
LSNMP
}
X60^] View the unit location.
SNMP passwords
Set public password
E
P
X60&
SNMP
}
Snmp P*
X60&]
Sets public password
to
X60&
.
Set public password
to default
E
P•SNMP
}
SnmpP*public
]
Sets community password
to the default.
View public
password
E
PSNMP
}
X60&] View the public password.
Set private password
E
X
X60*
SNMP
}
SnmpX*
X60*]
Sets private password
to
X60*
.
Set private password
to default
E
X•SNMP
}
Snmp X*private
]
Sets private password to
the default setting.
View private
password
E
XSNMP
}
X60*] View the private password.
SNMP access enable
Enable SNMP
access
E
E1SNMP
}
Snmp E*1
]
Enable SNMP access.
Disable SNMP
access
E
E0SNMP
}
Snmp E*0
]
Disable SNMP access.
View SNMP state
E
ESNMP
} X51)
]
View the SNMP access
setting.
NOTES:
X51) = 0 = Off or disable
1 = On or enable
X60% = SNMP contact name text, up to 64 characters (default="not specified")
X60^ = SNMP location, up to 64 characters (default="not specified")
X60& = SNMP public password, up to 64 characters (default="public")
X60* = SNMP private password, up to 64 characters (default="private")
Command and Response Table for Basic SIS Commands (continued)
73SMD101 • Remote Communication and Control
