Pull release handle : in the direction of
the arrow to the pressure point and hold it
in this position.
The backrest folds forwards.
X
Slide the seat in the second row of seats
forwards to the stop.
Entry position
EASY-EXIT feature
The release loop for the EASY-EXIT feature is
located at the bottom on the back of each
outer seat in the second row of seats.
X
Pull release loop : in the direction of the
arrow and hold it in this position.
The backrest folds forwards.
X
Slide the seat in the second row of seats
forwards to the stop.
Exit position
Moving the outer seats in the second
row back to the normal position
G
Warning!
When occupants have entered or exited the
vehicle using the easy-entry/exit feature,
before driving off make sure
R
the outboard second-row seats are
properly locked
R
the seat backrests of the outboard second-
row seats are in an upright position and are
properly locked
An outboard second-row seat is properly
locked only when lock status indicator : is
in hinged position and red marking ; is
barely visible.
If a seat and seat backrest are not properly
locked, the seat could move forward and the
seat backrest could fold. You could slide
under the seat belt during braking, vehicle
maneuvers, or in an accident. If you slide
under it, the seat belt would apply force at the
abdomen or neck. That could cause serious
or even fatal injuries.
106
Seats
Seats, steering wheel and mirrors
