Vehicle specification ML 450 HYBRID
(164.195)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz
Center for the corresponding data of all
special bodies and special equipment.
Engine ΜL 450 HYBRID
Engine, type
272
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
6
Bore
3.66 in (92.90 mm)
Stroke
3.39 in (86.00 mm)
Total piston
displacement
213.5 cu in
(3 498 cm
3
)
Compression
ratio
11.5:1
Output acc. to
SAE J 1349
1
275 hp/6 000 rpm
(205 kW/6 000 rpm)
Maximum torque
acc.
to SAE J 1349
258 lb-ft/
3 000 - 5 500
(350 Nm/
3 000 - 5 500 rpm)
Maximum engine
speed
6 000 rpm
Firing order
1-4-3-6-2-5
Poly-V-belt
2 398 mm
Hybrid ΜL 450 HYBRID
Type
Full hybrid
Concept
Two mode
Output EMA
83 hp
(62 kW)
Hybrid ΜL 450 HYBRID
Output EMB
80 hp
(60 kW)
Maximum torque
EMA
173 lb-ft (235 Nm)
Maximum torque
EMB
192 lb-ft (260 Nm)
System power
335 hp (250 kW)
381 lb-ft (517 Nm)
Electrical system ΜL 450 HYBRID
High-voltage
battery
288 V/45 kW
Battery
12 V/70 Ah
Spark plugs, type
Bosch Y 7 MPP33
Spark plugs,
electrode gap
0.031 in (0.8 mm)
Spark plugs,
tightening torque
15 - 18 lb-ft
(20 - 25 Nm)
Main dimensions ΜL 450 HYBRID
Overall vehicle
length
188.5 in (4 788 mm)
Overall vehicle
width
2
83.6 in (2 124 mm)
Overall vehicle
height
69.8 - 73.0 in
(1 774 - 1 854 mm)
Wheelbase
114.8 in (2 915 mm)
Track, front
64.7 in (1 644 mm)
Track, rear
64.8 in (1 647 mm)
Ground clearance
7.3 - 10.3 in
(186 - 261 mm)
Turning circle
39.0 ft (11.6 m)
1
Premium fuel required. Performance may vary with fuel octane rating.
2
Exterior rear view mirrors folded out.
