Specifications
qEngine
Item Specification
Type DOHC-16Vin-line, 4-cylinder
Bore×Stroke 87.5 × 83.1 mm (3.44× 3.27 in)
Displacement 1,999ml (1,999 cc, 122.0 cu in)
Compression ratio 10.8
qElectrical System
Item Classification
Battery 12V-36AH/5HR
Spark-plug number L3G2 18 110
*1
, L3Y118 110
Spark-plug gap 1.251.35 mm (0.0500.053 in)
*1 ex factory
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on
the iridium alloy and platinum tips could be damaged.
qLubricant Quality
Lubricant Classification
Engine oil
Refer to the recommendedSAE viscosity numbers
on page 8-22.
Manual transmission
oil
5-speed
transmission
Any temperature
API Service GL-4 or GL-5
SAE 75W-90
Above 10°C (50°F)
API Service GL-4 or GL-5
SAE 80W-90
6-speed transmission
API Service GL-4 or GL-5
SAE 75W-90
Automatic transmission fluid JWS3309
Power steering fluid ATF M-III or equivalent (e.g. Dexron®II)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
Rear differential oil
API Service GL-5
SAE
90
80W-90
75W-90
*1
*1 Not available from Mazda
