Filter
Top Products
High-Denition Digital Radar
Model Part
LRA-1800 for HDS 102-38
LRA-2400 for HDS 102-39
Model Part
GlobalMap
®
5150 116 - 3 2
Simrad NMEA 2000® heading sensor options to activate radar/chart overlay display.
FC40 Fluxgate Compass, includes 5M SimNet NMEA 2000
®
cable 22090187
FC42 Rate Gyro Fluxgate Compass, includes 5M SimNet NMEA 2000® cable 22090195
Required for both compasses above:
SimNet NMEA 2000
®
cable to Micro-C male 24005729
Yellow SimNet Joiner without Terminator 44172260
Lowrance N2K-T-RD NMEA 2000
®
T-connector 119 -79
16 17
www.lowrance.com
LRA-1800
LRA-2400
Advanced Lowrance digital signal processing in high-denition radome choices for
HDS. Fast, detailed radar detection of even small and distant targets with superb
accuracy in dark, fog and rain alike. Compact, dependable and high-performance,
both network with Ethernetworks for onboard radar display sharing.
LRA-1800 Radome
• 2 kW, 18”/46 cm scanner w/2 kW processor
• 5.2º horizontal beamwidth, 25º vertical
beamwidth
• Up to 24 nm range
NEW LRA-2400 Radome
• 4 kW, 24”/61 cm scanner w/2 kW processor
• 4º horizontal beamwidth, 25º vertical
beamwidth
• Up to 48 nm range
HDS Digital Radome Features
Radar/Chart Overlay.
Interfaces charts and radar detail in a single,
detail-rich display when coupled with an
optional, compatible NMEA 2000
®
heading
sensor.
Clearest Viewing.
Automatic Tune, Gain and Sea Clutter
adjustment.
Smart STC.
Digital Sensitivity Time Control curves reject
clutter with setting of return strength/distance
thresholds.
Colour Recognition.
Colour palette choices for improved target
distinction based on viewing conditions.
Radar range depends on fog, rain and other atmospheric conditions.
HDS high-denition radar display. Radar chart overlay display.
GlobalMap
®
5150C
A high-resolution colour Lowrance chartplotter with excellent features, precision
and versatility in a full-size format to t most boats. Non-NMEA 2000
®
or
Ethernetworks.
• Special 5”/12.7 cm diag. 640V x 480H pixel TFT colour display for excellent
viewing in sunlight and at wide angle
• Adjustable cold-cathode screen and keypad backlighting
• 12-channel GPS with external antenna and spat cone pole mount
• Outputs NMEA 0183 to link with DSC VHF or autopilot
• Compatible with Navionics
®
Gold and Lowrance NauticPath™ chartcards
• Stores up to 1,000 waypoints, 1,000 event markers, and 100 routes
• Saves up to 100 retraceable trails with up to 10,000 points in any trail
• Sealed and waterproof for the harshest marine environments
GlobalMap
®
GPS Chartplotter
